Cellular rubber can be used for water, air and oil seals.

There are different types of cellular rubber for different environments.

Cellular rubber is often very soft, which also makes it suitable for thermal insulation and sound absorption. Closed or semi-closed cells give the material its characteristic features



Daniel Fermskog, Horda Stans

Daniel Fermskog

Phone +46 370 65 47 11

E-mail daniel.fermskog@hordastans.se

Cellular rubber, Horda Stans

EPDM

Closed cells, for water and air seals.
Weight: 120-140 kg/m³
Temperature range: Min -40ºC Max +100ºC depending on quality
Fire class: FMVSS 302

Cellular rubber, Horda Stans

EPDM White

Closed cells, for water and air seals.
Weight: 120 kg/m³
Temperature range: Min -30ºC Max +75ºC depending on quality
Fire class: FMVSS 302

Cellular rubber, Horda Stans

EPDM Grey

Closed cells, for water and air seals.
Weight: 120 kg/m³
Temperature range: Min -30ºC Max +75ºC depending on quality
Fire class: FMVSS 302

Cellular Rubber, Horda Stans

NITTO 685 EPDM

Semi-closed cells, a soft cellular rubber material, used for sealing, good sound absorption properties
Weight: 130 kg/m³
Temperature range: Min -40ºC Max +135ºC(180ºC)
Fire class: FMVSS 302

Cellgummi, Horda Stans

NITTO 1000 EPDM

Semi-closed cells, a soft cellular rubber material, used for sealing, good sound absorption properties
Weight: 95 kg/m³
Tempeture range: Min -40ºC Max +135ºC(180ºC)
Fire class: FMVSS 302

Cellular rubber, Horda Stans

NITTO 1200 N EPDM

Semibold cells, depending on assembly but must be compressed 70%, seal at large gaps, water, wind, dirt, heat, good sound absorption properties.
Weight: 90 kg/m³, 5-30 mm.
Low emission standards: DIN 75201, VDA 270,275 och 277. UV resistant.
Temperature range: Min -40ºC Max +135ºC(180ºC)
Fire class: FMVSS 302 (10mm) <100 mm/min

Cellgummi, Horda Stans

NITTO 6800 EPDM

Closed cells, 33% comp load, for water seals
Weight: 110 kg/m³
Temperature range: Min -40ºC Max +135ºC(180ºC)
Fire class: FMVSS 302

Cellular rubber, Horda Stans

Condensate rubber

Insulation / protection for pipes, ventilation ducts, engine compartment
Synthetic, closed cells, high vapor permeability, low thermal conductivity.
Temperature range: Min -50ºC Max +110ºC
Temperature range HT-product: Min -50ºC Max +150ºCFire class tubes / sheets: B-s3,d0, UL approved V-0

Cellular rubber, Horda Stans

CR Cloropren

Closed cells, for water, air and oil seals.
Weight: 170-250 kg/m³
Can also be called neoprene.
Temperature range: -40º +100º
Fire class: UL94 HF >2mm

Cellular rubber, Horda Stans

NBR Nitrile

Closed cells, for diesel, petrol and oil seals
Temperature range: -40º +100º
Weight: 200 kg/m³
Fire class: UL94 HF

Cellgummi, Horda Stans

SI Silikon

Closed cells, good thermal features and electric insulation capacity.
Weight: 250 kg/m³
Temperature range: -80º +200º (+260º)
Fire requirements: FMVSS302

Cellular rubber, Horda Stans

PVC

Good at low temperatures -50 +70º, used for sealing
Weight: 105-120 kg/m³
